2023 Chevrolet Low Cab Forward 5500 XD 1WT



  • Call for Pricing & Availability Barlow Sale Price


Visit our Store

Vehicle Information

VIN: JALEEW161P7301910
Stock #: 1910U
Model Code: CT64003
  • Condition Used
  • Body Style Regular Cab
  • Exterior Color Arc White
  • Interior Color Medium Ash Gray, Cloth Seat Trim
  • Mileage 113,663
  • Engine 4 Cylinder Engine
  • Transmission Automatic
  • Fuel Type Diesel Fuel

Highlighted Features

Feature availability subject to final vehicle configuration. Please reference window sticker for more info.
  • Bluetooth®
  • Turbo Charged Engine
  • Cruise Control

Dealer Comments

CARFAX 1-Owner. 5500XD LCF Diesel trim. Running Boards, AUDIO SYSTEM, AM/FM STEREO WITH CD PL... PIO, MIRROR, OUTSIDE LEFT-HAND AND RI... ENGINE, DIESEL 5.2L 4 CYLINDER, TRANSMISSION, 6-SPEED AUTOMATIC AISIN...

KEY FEATURES INCLUDE
Running Boards Chevrolet 5500XD LCF Diesel with Arc White exterior and Medium Ash Gray interior features a 4 Cylinder Engine with 215 HP at 2500 RPM*.

OPTION PACKAGES
PIO, MIRROR, OUTSIDE LEFT-HAND AND RIGHT-HAND HEATED (Port Installed Option), ENGINE, DIESEL 5.2L 4 CYLINDER 215 hp [160.3 kW] @2500 rpm, 452 lb-ft of torque [612.8 Nm] @ 1850-2750 rpm (Governed). 16 valve, four cycle, chain-driven dual overhead camshaft valve train, a cast iron cylinder block, and a cast aluminum cylinder head. Turbocharged, inter-cooled, water cooled EGR, direct injection, electronically controlled common rail fuel system and engine cruise control. Oil level check switch and light. Engine warning system with audible warning for low oil pressure, high coolant temperature, and a protection system that will reduce fueling if excessive coolant temperature is detected (STD), TRANSMISSION, 6-SPEED AUTOMATIC AISIN A465 TRANSMISSION with fifth and sixth gear overdrive with lock up in 2nd, 3rd, 4th, 5th and 6th, PTO capability automatic torque converter lockup in stationary PTO mode. (STD), AUDIO SYSTEM, AM/FM STEREO WITH CD PLAYER, AUXILIARY JACK, USB PORT AND Bluetooth® (STD).

SHOP WITH CONFIDENCE
CARFAX 1-Owner

Horsepower calculations based on trim engine configuration. Please confirm the accuracy of the included equipment by calling us prior to purchase.

Eligible Benefits

All Features

  • Audio system feature, 2 speakers
  • Audio System, AM/FM stereo with CD player, auxiliary jack, USB port and Bluetooth® (STD)
  • Audio System, AM/FM stereo with CD player, auxiliary jack, USB port and Bluetooth® (STD)
  • Tires, front, 225/70R19.5 F 125/123 L BW HWY VAR1 (Standard on 4500XD, 5500HD and 5500XD only.)
  • Tires, rear, 225/70R19.5 F 125/123 L BW HWY VAR1 (Standard on 4500XD, 5500HD and 5500XD only.)
  • Windshield wiper, pulse, wet arm
  • Grille, Silver
  • Wheels, 19.5" x 6", K steel (Standard on 4500XD, 5500HD and 5500XD only.)
  • LED Headlamps
  • Assist steps
  • Glass, tinted
  • PIO, Mirror Bracket Extension adapts standard and optional outside mirrors for use with 102" wide body, (Port Installed Option)
  • Arc White
  • PIO, Mirror, outside left-hand and right-hand heated (Port Installed Option)
  • Lighting, interior dome
  • Windshield washer bottle access on passenger side dash when passenger-side door is open
  • Air conditioning, single-zone manual, integral in-dash mounted
  • Steering wheel, urethane
  • Steering wheel, tilt and telescopic
  • Floor mats
  • Windows, power
  • Cup holders
  • Cruise control, electronic, automatic
  • Seat trim, Cloth
  • Storage, door pockets
  • Storage, seatback pockets
  • Door locks, power
  • PIO, Extra Set of Keys provides customer with a total of 4 keys, (Port Installed Option).
  • Medium Ash Gray, Cloth Seat Trim
  • PIO, Seat, high back driver only torsion-bar with foam pads suspension system and fixed passenger seat (Port Installed Option)
  • Brakes, 4-wheel antilock, front and rear disc with traction control and stability control
  • Vehicle Application Truck
  • Wheelbase, 176" (447.0 cm)
  • Alternator, 140 amps
  • Emissions, 50 state certification
  • Incomplete vehicle certification
  • Rear axle, 5.57 ratio (Standard on 5500XD only.)
  • Drivetrain, rear-wheel drive
  • GVWR, 19,500 lbs. (8845 kg) (Standard on 5500XD only.)
  • Exhaust, single horizontal outlet
  • Frame, ladder-type channel frame. Full C section straight frame 33.5" (85.1 cm) wide. Yield strength 44,000 psi, section modulus 7.20 cu.in. and RBM 316,800 lb-ft/in per rail.
  • Rear Suspension, 14,550 lbs. (6599 kg) (Standard on 5500HD and 5500XD only.)
  • Front axle, 7275 lbs. (3300 kg), reverse Elliot "I"-beam (Standard on 5500XD only.)
  • Air cleaner, heavy-duty, 11" diameter dry paper single element. Air cleaner canister standard with air restriction gauge. Back of cab location.
  • Front suspension, 8,440 lbs. (3828 kg) tapered leaf (Standard on 4500XD, 5500HD and 5500XD only.)
  • Exhaust brake
  • Fuel tank, 30 Gallon, (113L), stainless steel includes 2 auxiliary fuel ports
  • Battery, dual 750 cold-cranking amps, 12 volt, maintenance free
  • Rear axle, 14,550 lbs. (6600 kg) (Standard on 5500HD and 5500XD only.)
  • PIO, Governor, speed limited to 68-mph (Port Installed Option)
  • Rear axle, 5.57 ratio
  • Preferred Equipment Group includes standard equipment
  • Ocean Freight Surcharge
  • Pre-Delivery Inspection Provides "Pre-Delivery Inspection" at the Port in cases where the vehicle needs to leave the port directly for the final stage manufacturing process and will not visit a dealer. NOTE: General Motors Company will not pay Dealer for Pre-Delivery Inspection, when this option is selected.
  • Daytime Running Lamps
  • DriveType
    • DriveType: Rear Wheel Drive
  • Fuel Economy
    • City: 0
    • Hwy: 0
    • Combined: 0
  • Fuel System
    • Fuel System: Direct Injection
  • Fuel Tank Capacity
    • Fuel Tank Capacity: 30 gal
  • Fuel Type
    • Fuel Type: Diesel Fuel
  • Horse Power
    • Horse Power: 215
  • Rear Wheel
    • Rear Wheel: Dual
  • Trailering Capacity
    • Trailering Capacity: 0
